Fig. 3


Download original image

TEM pictures of B4C irradiated at 4 × 1015/cm2 4 MeV Au ions. An amorphous zone appears in the (centre) implanted zone. Partial amorphisation was observed in the (left) front, damaged zone. Diffraction pictures: (left) at the middle of the speckled front zone; (centre) at the middle of the amorphous zone; (right) at the right amorphous-crystalline boundary (from Ref. [9]).
